GPU Engine Specs
CUDA Cores: 10752
Boost Clock (MHz): 2715MHz
Base Clock (MHz): 2295MHz
Thermal and Power Spec
Minimum System Power Requirement (W): 850W
Supplementary Power Connectors: 3x PCIe 8-pin cables (adapter in box) OR 1x 450 W or greater PCIe Gen 5 cable
Memory Specs
Memory Clock: 30Gbps
Standard Memory Config: 16GB
Memory Interface: GDDR7
Memory Interface Width: 256-bit
Memory Bandwidth (GB/sec): 960 GB/sec
Feature Support
Real-Time Ray Tracing: Yes
Ray Tracing Cores: 4th Generation, 171 TFLOPS
Tensor Cores: 5th Generation, 1801 AI TOPS
NVIDIA Architecture: Blackwell
Microsoft DirectX: 12 Ultimate
NVIDIA DLSS: 4
NVIDIA Ansel: Yes
NVIDIA FreeStyle: Yes
Bus Support: PCI Express Gen 5
NVIDIA ShadowPlay: Yes
OS Certification: Windows 11, Linux, FreeBSDx86
NVIDIA Highlights: Yes
NVIDIA G-SYNC™-Ready: Yes
Game Ready Drivers: Yes
NVIDIA Studio Drivers: Yes
NVIDIA GPU Boost™: Yes
Vulkan API: 1.4
OpenGL: 4.6
NVIDIA Encoder: 2x Ninth Generation
NVIDIA Decoder: 1x Sixth Generation
Accessories
Graphics Card Stand: Yes (embedded with cooler)
Graphics Card Dimensions
Length: 334mm
Height: 148mm
Width: 73mm
Display Support
Multi Monitor: up to 4
Maxmium Digital Resolution: 4K at 480Hz or 8K at 165Hz with DSC
HDCP: 2.3
Standard Display Connectors: 3x DisplayPort 2.1b, 1x HDMI 2.1b
